Lug Type Butterfly Valve Without Pin Ductile Iron DN200

Ref Price:

Loading Port:: China Main Port

Payment Terms:: TT OR LC

Min Order Qty:: 50

Supply Capability:: 20000 /month

Inquire Now

Add to My Favorites

OKorder Service Pledge

Quality Product, Order Online Tracking, Timely Delivery

OKorder Financial Service

Credit Rating, Credit Services, Credit Purchasing

You Might Also Like

High Quality Flanged Wafer Type Butterfly Valve

Wafer Butterfly Valve For Water, Oil, Gas

LT Butterfly Valve

Stainless Steel Sanitary Butterfly Valve

valve of china 3900

valve of china 7700

API Stainless Steel 316 Wafer Type Butterfly Valve

Butterfly Valve DN750 BS5163 with Hand Wheel

Centerline structure,pinless double half shaft design.
Disc has two-way bearing, no installation direction requirements.
Non-backed replaceable seat with good performance and a longer working life.
Square and short neck for lable use and cost saving.
Easy installation, no need flange gasket.

Size	DN50mm-DN600mm
Design standard	API609/EN593
End flange	DINPN10/PN16, BS4504PN10/PN16, ANSI class125#/class150#
Face to face	API609/EN558-1
Top flange	ISO5211
Body	Ductile iron/Cast iron
Disc	Ductile iron/CF8/CF8M/C95400/C95500
Stem	SS420
Seat	EPDM/NBR/Viton/PTFE
Actuator	Bare shaft/Lever/Gearbox and handwheel
Coating	Epoxy/Nylon/PTFE
Pin	With out pin
Suitable medium	Water/Seawater/Sewage/Air/Foodstuff/Oil

Q: What does "D341X-16Q" mean?What do D341-16Q letters and numbers mean for butterfly valves?: D - valve type code: Butterfly valve;3 - valve drive mode code: worm gear;4 - valve connection form code: flange;1 - valve structure type code: vertical plate type;X - seat sealing surface or lining material code: rubber;16 - nominal pressure value: PN1.6MPa;Q - body material code: QT400 - 15.

Q: What is the medium flow rate when the centerline butterfly valve is fully open?: The pressure test of the central butterfly valve is carried out at each station.Basis：1) GB/T12238-2008 flange and clamp connection elastic seal butterfly valveRules: butterfly valve must be carried out by factory inspection and testing, inspection qualified before leaving the factory.2) CJ/T 261-2007, butterfly valves for water supply and drainageRules: each product shall be inspected by factory and quality inspection department.

Q: What are the advantages of butterfly valves?: Butterfly valve, also known as shutter valve, its advantages are:A. has a large circulation capacity and is about 1.2 times the same size as two seat valves;

Q: Do you use the straight stem butterfly valve in the fire fighting engineering?: Only the gate valve clearly rod and dark pole, butterfly valve classification is the clamp type and flange type, Zhengzhou butterfly valve factory, Mr. Zhao

Q: What's the difference between cut-off valve, gate valve and butterfly valve? What's the difference in the working principle?: Gate valve, also known as gate valve, is a widely used valve. Its closing principle is that the gate sealing surface and the valve seat sealing surface are smooth and smooth, and they fit together to prevent the flow of the medium, and rely on the die shape of the top die, spring or gate to enhance the sealing effect. It mainly cuts off in the pipeline. The cut-off valve, also called the door, is the most widely used as a valve, it is popular is because the process of opening and closing the sealing surface friction between the small, more durable, highly open small, easy manufacture, convenient maintenance, not only for low pressure, but also suitable for high pressure. Butterfly valve with light characteristics, more than other valves to save material, simple structure, quick opening and closing, cutting and throttling can be used, the fluid resistance is small, labor-saving operation. Butterfly valve can be made into large caliber. Where you can use the butterfly valve, it is best not to make the gate valve, because the valve is more economical than the gate valve, and the regulation is good. At present, butterfly valves are widely used in hot water pipelines.

Q: What does butterfly valve do?: [1] butterfly valve is also known as turn over plate valve, is a simple structure of the control valve, but also can be used for low pressure pipe medium switch control.[2] butterfly valve: butterfly valve refers to the closure of parts (valve or butterfly plate) for the disk, around the valve shaft to achieve rotation and closing of a valve, the main cut off on the pipe and throttling role. Butterfly valve headstock is a disc shaped disc, in the valve body around its own axis of rotation, so as to achieve the purpose of opening or closing or regulation. Butterfly valve used in furnace, coal gas, natural gas, liquefied petroleum gas, city gas, hot and cold air, chemical smelting and power generation environmental protection engineering system, conveying a variety of corrosive and non corrosive media pipeline, used to adjust and cut off the media flow. Butterfly valve categories are: handle butterfly valve, turbine butterfly valve, pneumatic butterfly valve, electric butterfly valve and so on.

Q: Should I connect the butterfly valve before and after the pump? Or gate valve?: Personally believe that import and export butterfly valve or gate valve can be, or other valves. One principle, easy installation and easy maintenance.As for how much pressure can be selected according to the size of the pump flange to set the general small caliber pump are 1 and 1.6 pressure general, unless you are a super high pressure multi-stage pump, generally 1 flanges fully meet the requirements of pump working pressure is generally not too high, living above the water temperature will not exceed 40 C, so you choose the space is still very large.

Q: For example, the arrow above is from left to right, and the direction of my current is from right to left. Is that ok? I have a diameter of 700 of the hard seal butterfly valve is so installed, but it will leak water, it will not leak, very serious: The direction of the arrow on the valve body is cast, refers to the flow of media, users see the arrow, the arrow direction according to the logical and installation, this installation has become a habit, it is easy to accept the installation instructions, according to the national standard is not what error. But in the eccentric butterfly valve is installed so that sometimes there will be some problems, said the following example: according to the flow of eccentric butterfly valve with the medium flow consistent installation, tube medium is liquid, after the valve is closed, if the original direction of medium inlet pressure, reduced or zero, the export of medium reflux reflux, if senior supply, resulting in the high pressure medium, the pressure is greater than the inlet pressure, the valve will be subjected to reverse pressure, because the hard seal butterfly valve as a one-way valve so that the use is not conducive to sealing butterfly valve, and there will be leakage.

Q: Butterfly valves are widely used in 2.0MPa below the pressure and temperature of not more than 200 degrees of various media, right?: First of all, is not the butterfly valve butterfly valve.Butterfly valve in the valve around the fixed axis rotating valve, called butterfly valve.1., as a sealed butterfly valve, it has been developed rapidly since the appearance of synthetic rubber, so it is a new type of shut-off valve. In our country until 1980s, the main role of butterfly valves in low-pressure valves, valve seat using synthetic rubber, by 90s, hard seal "metal seal" butterfly valve to rapid development. There are a number of valve factory can produce steady pressure metal seal butterfly valve, butterfly valve shall be shipped to a broader area.2. butterfly valves can transport and control the medium with water, condensed water, recycled water, sewage, sea water, air, gas, liquid gas, dry powder, mud, fruit pulp and a mixture of suspended solids.The domestic butterfly valve parameters are as follows:Nominal pressure: PN0.25 - 4.0MPaNominal diameter: DN100 - 3000mmWorking temperature: less than or equal to 425 DEG C
