Fuel Tank Truck 8X4 40 Cbm Stainless Steel Full Traile
Product Details
Basic Info.
Model NO.:CA5310GYYT4
Transmission Type:Manual
Power:Diesel
Load Capacity:31-40t
Emission Standard:Euro 2
Tank Volume:＞30000L
Drive Wheel:8×4
Seats:≤5
Horsepower:251-350hp
Engine Capacity:＞8L
Storage:Oil
Tire Type:Inner Tube
Tire Certification:ISO
Tire Design:Radial
Condition:New
Truck Type:Tanker Truck
Type:Fuel Tank Truck
Driving:8X4
Brand:Faw
Volume:40cbm
Colour:Red, White, Blue
Export Markets:South America, Southeast Asia, Africa, Mid East, Eastern Asia
Additional Info.
Trademark:FAW
Packing:Nude Packing
Standard:ISO
Origin:China
HS Code:8703109000
Production Capacity:50PCS/Month
Product Description
Product: FAW rear double axles Fuel tank truck, refuel truck.
Chassis: CA1310P7K2L7T4EA80
Gross weight: 55000 (kg)
Rated payload: 35000 (kg)
Kerb weight: 18005 (kg)
Overall dimension: 11800X2480X3800 (mm)
Tank dimension: 9500X2300X1500 (mm)
Approach/ Departure angle: 14/10 (degree)
Front/ Rear suspension: 1375/2550 (mm)
Max speed: 85 (km/h)
Engine: CA6DE3-28E3 WP10.336
Displacement: 6618 9726 (ml)
Power: 280HP/ 336HP
Manufacturer: FAW/WEICHAI.
Emission standard: GB3847-2005, GB17691-2005 Euro 3
Axle Nos: 3
Wheelbase: 1800+5725+1350 (mm)
Front tread: 1914 (mm)
Rear tread: 1847 (mm)
Tyre no.: 12.
Tyre specification: 12.00R20, 12.00-20, 11.00R20, 11.00-20
Fuel type: Diesel
Leaf spring nos: 4/10
Axle load: 7500/26000
| Vehicle model | CA5403GHY Oil tank truck | Batch No. | 197 |
| Manufacturer | FAW | Brand name | FAW |
| Overall dimension(mm) | 11980×2480×3800 | Total weight (Kg) | 55000 |
| Body internal dimension(mm) | ×× | Curb weight(Kg) | 18000 |
| Approach/departure angle | -/12 | Max speed(km/h) | |
| Front/rear hang(mm) | -/2130 | Vehicle identification code | LFA |
| Chassis model | |||
| Engine model | Engine manufacturer | Emission | Power |
| FAW/ WEICHAI | Euro2 | 280hp,336hp | |
| Fuel type | Diesel | Tyre number | 12 |
| Axle number | 4 | Tyre specification | 11.00-20,11.00R20, 12.00-20,12.00R20 |
| Wheelbase | 1800+5730+1310 | Front wheel distance | - |
| Axle load | 9000-/26000 ( parallel ) | Rear wheel distance | 1840/1840/1840 |
| Leaf spring number | -/8/8/8 | ||
- Q: How many times a year do you need to drive a pickup truck?
- Then the staff will be the annual mark in your vehicle on the upper right corner of a paste, remind you of your car is limited to 2012, six years after every year in the annual time, after fifteen years every year in the annual two, twenty-one years after it belongs to scrap car.
- Q: Why do trucks need butter?
- The car is grease lubrication, oil hole now cars do not have buttered all bearings are oily, disposable without refueling, do not own the grease in the ball if you remove after filling will cause oil spills and other consequences of life. Above the coach, the SUV is topped with butter, because it has a chassis and a butter mouth.
- Q: C1 can I drive a minivan?
- The blue card hanging on the line, six meters. But it seems that the driver has to have a freight certificate
- Q: What happened to the front wheel jump?
- A freight car is a commercial vehicle designed and equipped primarily for carrying goods. It can be used to tow a trailer. Also called a truck, a car that is used primarily for transporting goods, and sometimes a vehicle that pulls other vehicles, belonging to the commercial vehicle category.
- Q: How do you know the horsepower of a large truck?
- 184kw is the power of the supercharged engine, which is the rated power under the normal operation of the supercharger. For supercharged engines, if the supercharger does not work, it will worsen and the engine will not work properly.
- Q: What's the van for the new car?
- Sedan car, also known as vehicles, trucks, monsters, two strange, etc.There are three types of vehicles in the form of structure: Double Bridge twin, double bridge single tire and single bridge twin. According to the appearance, they are divided into skeleton type, half closed type and enclosed type.The car can be made according to the customer's requirement, the length is different, and the frame is welded I-beam. The whole body adopts full automatic submerged arc welding and carbon dioxide gas shielded welding. After the welding is completed, shot peening is carried out to eliminate the welding stress and improve the adhesion of the paint surface, so that the quality is stable and the appearance is beautiful. The upper chassis can be divided into two to three blocks, with a hoist and an oil cylinder to adjust height. The closed front sheet is made of small corrugated board skin, and the side is made of corrugated board or stamped corrugated board, and the top is covered with tarpaulin and tarpaulin. The whole vehicle has a kit, a spare tire rack, and a drip brake system installed to improve the safety of vehicle transportation.
- Q: What documents do you need for a pickup truck?
- The driver must have a driver's license (C1 above) operating certificate; to apply for vehicle driving permit, additional fees, road maintenance fees, transportation management fees, insurance, small goods (1T) a year costs about 4000 to 5000 yuan on the road to engage in profitable transportation, handling the operating documents, the driver must have "the driver qualification certificate". If there is no traffic inspection departments checked, according to traffic law, the driver fined 100-200 yuan, the vehicle unit fined 1000-2000 yuan.. In general a fine below 500 yuan, if the use of false absolute fined 2000 yuan.
- Q: What's the difference between a truck and a truck?
- The car looks ugly and the truck looks good. The loan car is for loan, and the truck is not for loan.
- Q: Can Ford F150 pickup go to town?
- Yes, the Ford Raptor belongs to the minivan. Less than 6 meters, on the blue card, the C can travel. The road limit for lorries is strictly prohibited
- Q: What's the advantage of truck tyres?
- Disadvantages are, but because the tire increases, inevitably or lead to increased rolling resistance, fuel consumption increases, power output will become weak.
