Specification

Van,Pickup Air-Conditioner Roof Mounted

1.Rooftop Air Conditioner Description:

Parking air conditioner is a kind of air conditioner in the car, which means that when parking, waiting and resting, the car battery DC power supply (12V/24V/110V/220V) is used to keep the air conditioner running continuously, and the temperature, humidity and flow rate of the ambient air in the car are affected. It is a device that can adjust and control other parameters, and repeatedly meet the comfort and cooling needs of car drivers. The device can be divided into one machine and one machine, suitable for any model, the cooling capacity can reach 1800-2500W, and it can still be used for 8 hours after the car is turned off.

Parking air conditioning works independently of the vehicle's motor, which means that no fuel needs to be consumed and no combustion gases and noise are emitted.

It is supplied from the vehicle's electrical system .

We have a variety of specifications and can be customized. Welcome to consult!

This is the most popular truck parking air conditioner on the market.

The truck air conditioner is divided into two types : Rooftop Air Conditioner/ split type model.12v and 24v both available and easy to install.

2.Main Features of the Light Rooftop Air Conditioner Description:

• Electric Scroll Air Compressor Using:Use Electric Scroll air Compressor Consume less fuel but faster cooling and better drive and lower noise.

• Light weight designs:Made from ABS ultra light shell , resistant to high temperature aging, it made the rooftop air conditioner streamline fashionable and safe.

• 12 V /24V DC Drive：Compared with traditional car air condition fuel driving, electric can use at the time of flame-out.

• Vehicle type:RVs, trucks, trucks, engineering excavators, cranes, forklifts, mechanical vehicles, yachts, boats, mobile dining cars, Ferris wheels, bus etc.

3.Specification of Air Conditioner:

4.Accessories of Packing Air Conditioner:

The entire air conditioner is integrated, with compressors, condensers, blowers and other accessories inside.

One year warranty and three years warranty for compressor

        Cooling capacity: ≥2.5kW

        Air volume: ≥300m³/h

        Evaporator: copper tube fin heat exchanger

        Condenser: All-aluminum micro-channel heat exchanger

        Compressor: Elec scroll compressor

        External fan: brushless dual fan

        Features: detachable cleaning filter; ultra-clear

        Clear digital large screen display; dual brushless fans,

        Fast heat dissipation, better cooling effect; large

        Grille air outlet design, the front and rear angles can reach

        90°.

1)Electric Scroll Comprssor

As we know the compressor is core of air conditioner,like a heart for the air conditioner,driving air refrigerant like blood to all body.

The Electric Scroll Comprssor manufacture by our-own factory.

It has some features compared to traditional air compressor.

1)Electric car air compressor is small size, low noise, light weight and small vibration, low energy consumption,

long life, continuous and stable gas transmission, reliable operation，clean gas source, etc.

2）Solve the problem that no air conditioner after flame-out.

Normal using after flame-out and less vibration and less noise.

3)Promote comfortability of driving and rest.

instead to drive the diesel fuel or gas fuel,much more energy-saving and less vibration and less noise.

2）Evaporator:

Widened and enlarged pure copper evaporator 560X150mm

The design applies a 45° tilt, so that the height of the entire product is controlled at 140mm,

Don't be afraid of height limit roadblocks, all the way unimpeded.

3）Evaporator fan:

Ultra-quiet cross-flow fan

4)Evaporator Centrifugal fan:

Ultra-quiet low-energy brushless fan

Neat and compact internal car-level design and equipment

In a limited space, while ensuring the effect, it does not increase the heaviness of the product

Proper use of 3-point capillary copper tube increases the use effect and service life of the product
