Fuel Tank Truck Df Q235 Carbon Steel Semi Trailer (25-60M3)
Product Details
Basic Info.
Model NO.:CLW5512
Transmission Type:Manual
Power:Diesel
Load Capacity:11-20t
Emission Standard:Euro 4
Tank Volume:10001-15000L
Drive Wheel:4×2
Seats:≤5
Horsepower:150-250hp
Engine Capacity:4-6L
Storage:Oil
Tire Type:Solid Tire
Tire Certification:ECE, GCC, ISO, DOT
Tire Design:Tubeless
Condition:New
Loading Capacity(Kg):9865
Tanker Capacity(Cbm):15
Max Speed(Km/H):75
Type of Fuel:Diesel
Number of Axles:2
Color:Red, Yellow, Camo, Any Color as Your Request
Brand:Dongfeng
Drive Mode:4X2
Price Term:FOB, CIF
Delivery Time:25 Days
Export Markets:Global
Additional Info.
Trademark:CLW
Packing:Naked, Waxing and So on
Standard:ISO, CCC
Origin:Hubei. China
HS Code:8705909990
Production Capacity:800sets/Month
Product Description
| Description | DF Q235 Carbon Steel Fuel Tank Truck | ||
| Drive Model | 4X2 | ||
| Chassis | EQ1160 | ||
| Number of axles | 2 | ||
| Vehicle Main Dimensions | Dimensions(L x W x H)(mm) | 9000×2490×3100 | |
| Wheel base (mm) | 4950 | ||
| Overhang (front/rear) (mm) | 1250/2800 | ||
| Wheel track (front/rear) (mm) | 1940/1860 | ||
| Approach/Departure angle(°) | 28/12 | ||
| Weight in KGS | Curb Weight | 6125 | |
| GVW. | 15990 | ||
| Max. driving speed(km/h) | 75 | ||
| Engine | Model | ISB190 40 | |
| Type | 4-stroke direct injection , 6-cylinder in-line with water cooling, turbo-charging and inter-cooling | ||
| Horse Power(HP) | 190HP | ||
| engine capacity(L) | 5900 | ||
| Emission standard | Euro IV | ||
| Gearbox | 6 forwards & 1 reverse | ||
| Clutch | Reinforced diaphragm clutch | ||
| Steering Gear | Power steering, hydraulic steering with power assistance | ||
| Fuel tank (L) | 180 | ||
| Tire | 10.00-20 tire , 6 + 1(spare) | ||
| Brakes | dual circuit compressed air brake | ||
| Tank | |||
| Material | Q235A Carbon steel | ||
| Medium | Oil ....... | ||
| Loading Capacity (m³) | 14.5 | ||
| Overall dimensions(mm) | 6300×2350×1450 | ||
| The back of the protective | section size (mm) | 100×50×5 | |
| ground height (mm) | 500 | ||
| Thickness(mm) | 6 | ||
| ABS model | 3631010-C2000 | ||
| Equipment | 1. Tank can be separated to several unattached small tanks to fill different fuels 2. Tank material: carbon steel,stainless steel,FRP etc. optional 3. Tank shape: Roundness , quadrate , oval optional 4. Oil pump: self-priming pump,gear pump optional 5. Oil meter:single,double,Fiscal processor optional 6.Equipped with valves and pipes,a set of Fuel Dispenser 7.Equipped with a ladder on tank 8.Install with the motion of the satellite positioning function recorder | ||
- Q: Do pickup trucks charge the same rate as cars?
- And holidays free vehicles do not include pickup trucks.High-speed toll:Small cars 2 tons (including 2 tons) of the following trucks, 20 passenger cars below 0.45 yuan / kmMedium vehicles, more than 2 tons to 7 tons (including 7 tons) trucks, more than 21 to 50 buses, 0.90 yuan / kmLarge vehicles over 7 tons to 20 tons (including 20 tons) trucks, more than 51 passenger cars, sleeper bus 1.462 yuan / kmOversize car 20 tons of above freight car, container car 2.138 yuan / kilometer
- Q: Do pickup trucks belong to minivans or license plates?
- Pickup trucks are small vans in China. If they want to be a family car, they'd better be refitted, with a cover at the back and a van
- Q: How many kilometers is the wagon maintained?
- The 1. engine through the filter Sanqing after the operation, should be easy to start, smooth operation, normal exhaust (refers to exhaust), water temperature, oil pressure requirements, smooth speed, abnormal sound, the belt tension is moderate, no leakage four (water, oil, electricity and gas) phenomenon.The 2. direction free travel and the front beam meet the requirements. The steering is light, flexible and reliable. When driving, the front wheel has no left or right swing head and deviation.3., the clutch free travel meets the requirements, easy operation, separation, complete, stable combination, reliable, no noise, hydraulic system without oil leakage.4. transmission box, drive axle, universal joint (or half shaft), transmission device and other lubrication good, reliable connection, no noise and overheating, do not jump gear, flexible gear, no oil leakage.5. brake pedal free stroke and brake intermittent meet the requirements, driving, parking brake good, no deviation phenomenon when braking and brake drag delay phenomenon, the inertia proportional valve works normally, no oil leakage.6. the tire pressure is normal (different models specify high and low voltage standards are different).7., cantilever, shock absorption, fixed and reliable, function is normal, the hub bearing temperature is not high fever after driving.8. generator, starter, light, instrument, signal lamp, button, switch, accessory equipment is complete and complete, can work normally.9., the whole car lubrication points filling lubricating oil.10. all car wash clean.
- Q: Why is the van a diesel?
- Although the existing problems in the use of diesel vehicles, but this is caused by inadequate technical level, rather than the nature of the diesel engine, it can be solved through technological progress. So, including home cars, diesel engines are a trend
- Q: The maximum size of the blue gondola
- You can hang blue light trucks and mini trucks, truck classification method is:Truck is divided into light, medium-sized, heavy three. Each country classification method and standard are not the same, China is according to the automobile load classification, the carrying capacity of less than 3.5 tons of light truck, 4~8 tons of medium-sized truck, more than 8 tons for heavy truck.
- Q: How can farm cars and trucks be distinguished?
- First of all, to distinguish between the two cars what is the difference between the first to find out the definition of the two cars.
- Q: What do you mean by the 6X2, 6X4 driving methods of the trucks?. Please say more details
- The 6 refers to the vehicle a total of 6 heads is 3 axes, 2 refers to the 2 axis is an axis is driven, in the same way, 6X4 refers to the 3 axis, 2 axis drive, the number and the wheel is Never mind, only the total number and the axis and the number of the drive shaft.
- Q: Truck modification problems and penalties
- Without changing the shape of the vehicle (such as the modification of the exhaust tube, increase body surrounded by large, large rear spoiler) and relevant technical data have been registered, restitution by the traffic administrative department of the public security organ shall order, and impose a warning or a fine of five hundred yuan.
- Q: What are the brands of truck gearboxes?
- The most famous is the Shaanxi Fashite, followed by Zhejiang, Chongqing Jiaka WanLiYang, Zhejiang Jinhua, Shanxi Datong, micro goods is SUZUKI. The rest is less well-known, or the car manufacturers themselves, and the name of the manufacturer and a name. For example, the car heavy Howard first installed fast gear box, then they imitate Fashite produced gearbox, called Howard gearbox.
- Q: How do you calculate the freight rate?
- The freight is generally paid by the consignee. There is a shipper's package charge.. If you are looking for a carrier, if the shipper is the best to find a local logistics company negotiated tariffs. See the road and the weight of the goods and judge the customs.
