City Bus Used in City DD6109S23/S24
- Ref Price:
-
- Loading Port:
- Dalian
- Payment Terms:
- TT or LC
- Min Order Qty:
- 1 unit
- Supply Capability:
- 10 unit/month
OKorder Service Pledge
OKorder Financial Service
You Might Also Like
Engine
DD6109S23 | DD6109S24 | |||
Model | CA6DF3-22E3 | SC8DK230.1Q3 | YC6G240-30 | YC6J220-30 |
Type | 6 cylinder in line, 4-stroke, water cooling, air-air intercooler, turbo diesel engine | |||
Displacement（L） | 6.618 | 8.3 | 7.8 | 6.5 |
Max torque (Kw/rpm) | 860/1300-1700 | 920/1400 | 950/1200-1500 | 800 / 1200-1700 |
Max power (N.m/rpm) | 162/2300 | 170/2200 | 177/2200 | 162 / 2500 |
Fuel tank（L） | 200 | |||
Chassis
DD6109S23/S24 | |
Model | DD6109S23/S24 |
Clutch | Single leaf, dry coil spring |
Transmission | Manual mechanical transmission with synchronizer |
Rear axle | Integral stamping and welding type, single reduction |
Suspension system | Leaf spring with dual acting telescopic shock absorber and stabilizing bar |
Main reduction ratio | 5.143 |
Tire | 10.00-20 Optional: 11R22.5 |
Steering system | Integral hydraulic power steering |
Service brake | Air drum brake, double circuit |
Parking brake | Energy storage spring, air cut-off actuating on rear axle |
Dimension（mm）
DD6109S23/S24 | |
Length | 10490 |
Width | 2482 |
Height | 3100(3300 without A/C) |
Wheelbase | 5000 |
Tread（F/R） | 2020/1860 |
Approach/Departure angle（°） | 7/7 |
Min ground clearance | ≥200 |
Internal height | ≥2274/1998 |
One step height from ground | ≤380 |
Main Body Equipments
DD6109S23/S24 | |
Passenger door | Single-leaf inward swing door before front wheel, double-leaf inward swing door before rear wheel |
Window | Laminated front window shield, tempered glass for other windows, bonded type for side windows |
A/C | Optional |
Heating system | Optional |
Service Facilities | Optional: stop announcer, line board, reverse monitor, curtain, tire cover, etc |
Weight（kg）
DD6109S23/S24 | |
Gross weight | 15500 |
Curb weight | 10200/10500 (with A/C) |
Number of seat | 80,75/24-39 |
Seat Layout | F 1+1 R 2+2 or 2+2 |
Performance
DD6109S23/S24 | |
Max speed（km/h） | ≥90 |
Min turning diameter（m） | ≤22 |
Max grade ability（%） | ≥20 |
Fuel consumption（L/100km） | ≤26 (under given condition) |
