1.Work with TM/iB card

2.Low voltage alarm

3.Low energy consumpition

4.CE/RoHs Certificated

5.For Sauna/Hotel/School/Spa

6.Model: C1000D-12GX Sliver

Features

1.4-Lever Managemen

-1st lever: Owner Key(1 iB Card) is used to issue or delete Master Key or Master Code, and emergent opening

-2nd lever: Master Key(Max. 5 iB Cards) or Master Code (1 set) is used to issue or delete User Key or User Code, and servise opening

-3rd lever: User Key (1 iB card) or User Code(1 set) is for guest opening.

2.Keypad with Background Light

The Keypad with background light is easy for user to operate in dark environment.

3.Fault Tolerant Input

Any incorrect digits code can be input before inputting the correct code.

4.Hidden handle design

5.Low power consumption

4 standard AA size alkaline batteries can last more than 16,000 cycles.

6.3 working modes can be selected for the 3rd lever opening:

1. Owner Key Opening

2. Master Key Opening

3. User Key opening

7.Notifications with LED light and buzzer

In combination with LED and buzzer, notifies user any operations and errors.

Incorrect code alarm

Buzzer Alarm for 60sec after 4 incorrect attempts

Illegal Key Alarm

Buzzer Alarm for 60sec after 4 incorrect attempts with an illegal iB card

Anti-thief alarm(ATA)

Buzzer alarms for 60sec when latch be pressed or picked

Low-Voltage Alarm

Buzzer Alarm when unlocking under the voltage DC4.2V+/-0.2, notifies to replace new batteries.

Tech Index

Power Supply : DC4.5V, use of 3 pieces of AA batteries

Supply Voltage : Below DV4.5V with lack of voltage indications and can use about 200 more times.

Latch length: 15mm

Door thickness: 15-30mm

Working temperature: -20~+55
