EPDM Waterproof Membrane
1. Description of EPDM Waterproof Membrane:
CMAX EPDM waterproof membrane is of high elasticity with best performance among high polymer waterproof material it’s made of ternary ethylene-pro-pylene rubber.
We owe the world-advanced equipment of cold feeding extrusion and continuous vulcanization technology. With the best performance among high polymer waterproof materials, EPDM is of exceptional elasticity and will not split or cracked under normal building movement.
2. Specification of EPDM Waterproof Membrane:
Type | EPDM Rubber Waterproof Membrane | ||
Type | Vulcanized and Weldable | ||
Thickness | 1.2mm | 1.5mm | 2.0mm |
Weight(kg/m2) | 1.54-1.58 | 1.79-1.83 | 2.25-2.29 |
Size | 1.2m (width) * 20m (length)/roll. Weldable type could be 4m wide. | ||
Packing | 24㎡/roll, with plastic bag. (Weldable: 80㎡/roll) | ||
Usage | Roof, basement, pond, Lake, steel structure roofing, underground, tunnel, etc | ||
3. Technical Data Sheet of EPDM Waterproof Membrane
NO.
Item
Unit
Technical requirement
1
Tolerance on size
Thickness
%
±10
Width
%
±1
length
%
Does not allow negative
2
Fracture tensile strength (normal temperature )
Mpa
≥7.5
Fracture tensile strength(60 ℃)
Mpa
≥2.3
3
Breaking elongation,(normal temperature )
%
≥450
Breaking elongation,(-20 ℃)
%
≥200
4
Tearing resistance
KN/m
≥25
5
Impermeability
*
0.3Mpa impermeable
6
Bending at low temperature
°C
≤-40
7
Elongation and contraction volume at heating
Elongation
mm
≤2
contraction
mm
≤4
8
Hot air aging 80°CX168h
Fracture strength retention
%
≥80
Rate of elongation at break
%
≥70
9
Alkaline (saturated Ca(OH)2 solution normal
Temperature x2 168h )
Fracture strength retention
%
≥80
Rate of elongation at break
%
≥80
10
Ozone aging (40 degree by 168 hours )
Elongation 40% , 500x10-2
*
No Crack
11
Phytotron aging
Fracture strength retention
%
≥80
Rate of elongation at break
%
≥70
4. Property of EPDM Waterproof Membrane:
1) Excellent anti-aging performance, service life up to 50years;
2) High extension rate, high tensile strength, small size changes at heat treatment;
3) Good plant roots penetrability resistance and can be made waterproofing layer of planting roof;
4) Special modified molecular structure, effectively resolving the current domestic and foreign glue joint problem;
5) Good low temperature flexibility, and good performance of adapting to ambient temperature changes;
6) Convenient application, solid joint, no environment pollution;
7) Chemical corrosion resistance, can be used for special occasions;
8) Convenient maintenance, low costl
9) Convenient for dealing with details;
10) Good anti-perforated.
Application of EPDM Waterproof Membrane:
1) Roof, Basements, Tunnels
2) Industrial and civil building waterproofing
3) Geosynthetic liner for fish ponds, swimming pools, channels, irrigation system.
Especially suitable for projects with high requirement in durability, anti-corrosion and deformation
FAQ:
1. What are we supplying?
We are specialized in producing , geocell, geogrid, geomembrane, geotextile, waterproof membarne, etc.
2. How Many years experience do we have?
We have been exported to more than 15 countries in the past 13 years.
3. How long do we usually reply your request?
We always reply our customer within 8 hours.
- Q:500 grams thickness of 0.3 mm geomembrane a square meter two cloth a film how much money
- I professional geomembrane manufacturers, how much? bargain!
- Q:Are geomembranes resistant to puncture from tree roots?
- No, geomembranes are not typically resistant to puncture from tree roots.
- Q:What are the advantages and disadvantages of membrane pressure cupboard drawer?
- Generally mould pressing board is also called PVC board. the substrate for the board is density board, surface is uptaken by vacuum or pressure molding process using a seamless membrane, it is the most mature cabinet material, and it is the most convenient and most suitable material for people living. The door board in the normal size needn't to be sealed the edge, waterproof, moisture-proof, good hardness and good toughness. China cabinet top ten enterprises cocoro remind you of the advantages of cabinet: No cracking, no deformation, scratch resistant, stain resistant, anti fading. Disadvantages: Because the surface is membrane, so the performance of high temperature resistance is poor.
- Q:Are geomembranes resistant to stress cracking?
- Yes, geomembranes are generally resistant to stress cracking. They are designed to withstand environmental stressors and can tolerate heavy loads, making them highly durable in various applications.
- Q:How to deal with the bubbles in the mobile phone film?
- 1, Firstly, you should clean up the dust and oil stain on the your hand by the hand sanitizer. 2, Use the glasses cloth or the soft cloth with no hair?slip dip in a small amount of water to wipe the surface of the phone, and the clean up the dust and fingerprints on the surface. 3, tear the one side of protective film, and then alige at the top and sides of mobile phone and paste the film. 4, When you paste the film, you should maintain constant speed, please pull back the film if there is bubble, in order that there is no bubble on the surface of film. Then use the wool or cushion scraper to avoid scratching. The film will be slowly pressed on the surface of the mobile phone, even if there are the bubbles, they will be less. 5, After finish the pasting, you should treat the regional bubbles. Use the hard card and credit card which are wrapped by the screen soft to slowly scrap the bubbles out of the edge. 6, If there is a small dust particles on the surface, please disclose the whole film, stick up the particles by the adhesive tape, and then paste the film.
- Q:How do geomembranes handle seismic events?
- Geomembranes are designed to handle seismic events by providing a protective barrier that prevents the release of hazardous materials and contaminants. These flexible liners are made from durable materials such as high-density polyethylene (HDPE) or polyvinyl chloride (PVC) that can withstand ground movements during earthquakes. The geomembranes are installed in a way that allows them to absorb and distribute seismic forces, minimizing the risk of damage or rupture. Additionally, proper anchoring and securing techniques are employed to ensure the geomembrane remains intact during seismic events.
- Q:HDPE geomembrane related
- HDPE geomembrane in the anti-seepage construction quality inspection method 1: laying anti-seepage membrane should be civil engineering corresponding to the corresponding acceptance of documents. 2: anti-seepage film before cutting, it should accurately measure the relevant size, and then according to the actual cutting, generally should not be cut according to the size of the figure, should be piece by piece number, detailed records in the special form. 3: laying impermeable membrane should try to weld at least, in ensuring the quality of the premise, as far as possible to save raw materials. But also easy to ensure quality. The lap width of the joint between the membrane and the membrane is generally not less than 10 cm, usually in the direction of the weld arrangement parallel to the maximum slope, that is, along the slope direction. 4: usually in the corner and the deformity of the lot should be shortened in length. In addition to the special requirements, in the slope of more than 1: 6 on the slope from the top of the slope or stress concentration area of 1.5 meters, as far as possible without weld.
- Q:What are the specifications of DNP aluminum plastic film?
- The specifications of DNP aluminum plastic film: Aluminum plastic plate can be roughly divided into interior decoration board and exterior decoration (curtain wall) board. The specification of aluminum plastic plate used in interior decoration is about 1.22m×2.44m×3mm. The thickness of exterior decoration is about 4mm. The size is not fixed, and they are generally customized.
- Q:What are the advantages of high density polyethylene HDPE geomembrane ?
- High density, good anti-seepage ability, light weight.
